Fissure Carbide Bur HP / FG

Fissure Carbide Bur HP / FG

Specially designed with a unique trigonal pyramid shaped tip or perfect pointed-end for a variety of applications such as:

  • Anatomical carving of pit & fissure
  • Minor adjustment of interproximal area of bridges fabricated with porcelain, indirect composite, hard resin, denture base acrylic and a range of dental alloys
  • Trimming of interdental papilla of denture
  • Trimming the inner surface of crowns
  • Removal of porosities and excess materials


  • The special three-blade design is highly abrasive with superior cutting efficiency to provide precise replication of intricate surface details
  • Made of tungsten carbide, these carbide burs assure remarkable durability
  • Available in FG & HP shank for laboratory use
  • The Fissure Carbide in FG Shank for use with Lab Air Z is preferred by ceramists for anatomical carving of grooves and fissures in porcelain restorations
  • The Fissure Carbide in HP Shank is used for carving of indirect composites (eg. Ceramage) as well as acrylic dentures

Recommended Speed Range (FG):
25,000 – 450,000 rpm


  • Fissure Carbide in HP: Plastic Case of 6’s
  • Fissure Carbide in FG: Plastic Case of 3’s

Safety Data Sheets

Fissure Carbide
